HS423C

Descriptions

Gas gap heat switches are generally used to speed up the cool-down process in dilution refrigerators as well as to control thermodynamic cycles in adiabatic demagneti-zation refrigerator.The fundamental principle is by charging or discharging helium gas ((³He或4He) inside a small gap between two copper fingers, heat transfer can turn on or off between these two copper fingers. Lihan provides a series of standard heat switching products for extreme low temperature refrigerators. Tailor design can also be offered upon user request.

Features

High switching ratio>2000
Low adsorbent heating power<10mW
Minimum ON-state thermal conductance>100mW/K

Specifications

Working Temp.	4 K
Nominal Length	258 mm
Mounting Thread	M12 mm
Weight	0.63 kg
Switch Ratio	>2000
ON-state Thermal Conductance	100 mW/K
Adsorbent Heating Power	<10 mW
